3510 Series
Its whole job is getting out of the way.
A full-width preamplifier with discrete Class A output buffers and a custom-wound toroidal transformer, drawing under 25 watts to do one job properly. Designed and built in Lancing, West Sussex.
Exposure 3510 Preamplifier
Popular upgrades
Pairs well with
Designed and built in Lancing, West Sussex since 1974. Three-year guarantee.
Exposure 3510 Preamplifier
Separates
Exposure has been splitting pre from power since the Roman numerals.
- XMHalf-width separates. Phono, integrated, pre, mono, headphone, CD.
- 2510Full-width. Seventy-five watts, with an MM phono stage as standard.
- 3510The complete tier. Integrated, pre, stereo power, monoblocks and CD.You are here
- 5510The current flagship. One hundred and twenty watts, black only.
Within this tier
Distortion, Noise, Draw
What a line stage is for.
Measured at 1 kHz, referenced to rated output. Six times lower than the same tier's integrated amplifier, which is what taking the power stage out of the box buys you.
A-weighted, and the floor a preamplifier has to hold if the amplifier behind it is to have anything clean to work with.
A line-level box has no business drawing more. Discrete Class A output buffers, and a custom-wound toroidal transformer with hum shielding.
Technical specifications
| Output level | 1.9 V for rated input (gain +18 dB, full volume) |
| Maximum output | 7.7 V RMS @ 1 kHz |
| Total harmonic distortion | <0.005% @ 1 kHz, ref. rated output |
| Frequency response | 20 Hz β 20 kHz Β±0.25 dB |
| Signal-to-noise ratio | >100 dB (A-weighted) |
| Input impedance | 18 kΞ© minimum |
| Input sensitivity | 250 mV |
| RCA sockets | Chassis-mounted β threaded shank through the rear panel, secured with a nut |
| Mains supply | 110/120 V or 220/240 V, 50/60 Hz, factory set |
| Power consumption | <25 W |
| Dimensions and weight | 440 Γ 90 Γ 315 mm (W Γ H Γ D), 7 kg net / 9 kg gross |
Why buy a separate preamplifier instead of the 3510 Integrated?
Can it take a phono or DAC board?
What power amplifier should follow it?
Where is it built?
About the Exposure 3510 Preamplifier
Reference Thinking, Real-World Price: Exposure 3510 Preamplifier
The Exposure 3510 Preamplifier is a high-end British preamp inspired by the award-winning 5010 reference design β and built to punch well above its price. A new gain stage with high-quality relays and an oversized toroidal power supply deliver clarity and quiet that belong to far dearer components. Hi-Fi News gave the 3510 pre/power its "Outstanding" badge, noting a design in which "simplicity has been elevated almost to an art form."
Discrete, Quiet, and Beautifully Simple
Inside, discrete transistors in the line stage and an optimised PCB layout keep crosstalk low, while a carefully designed hybrid power supply achieves very low residual noise. The result is a preamplifier that gets out of the music's way. Controls are refreshingly minimal β no cluttered menus, just clean, intuitive operation and a newly designed remote that switches inputs, mutes, and controls volume from your chair.
Configure It Your Way
Plenty of inputs are provided, with slot-in options for onboard MM phono, MC phono, or a high-resolution DAC β so you build exactly the preamp your system needs and nothing you don't. The aluminium front plate and chassis aid cooling and keep noise at bay, in black or titanium.
Why You'll Love the Exposure 3510 Preamplifier
- 5010-reference inspired β flagship design thinking at a fraction of the price
- New relay-switched gain stage β clean, precise, channel-matched control
- Oversized toroidal PSU β quiet, stable power for a black background
- Modular options β add MM phono, MC phono, or a hi-res DAC board
- Discrete line stage β optimised layout for low crosstalk and noise
- "Outstanding" β Hi-Fi News β remote included, black or titanium
Frequently Asked Questions
Can I add a phono stage or DAC to the 3510 preamplifier?
Yes. The 3510 preamp accepts slot-in option boards for moving-magnet phono, moving-coil phono, or a high-resolution DAC, so you can tailor it to your sources.
What power amplifier should I pair it with?
The Exposure 3510 stereo power amplifier or 3510 mono power amplifiers are the natural partners, forming the "Outstanding"-rated 3510 pre/power system.
Does it come with a remote control?
Yes β a newly designed remote lets you switch inputs, mute, and adjust volume from your listening position.
Exposure 3510 Preamplifier Technical Specifications
| Type | Line preamplifier with optional phono/DAC boards |
| Gain stage | New design with high-quality relays; discrete transistors |
| Power supply | Oversized toroidal; hybrid low-noise design |
| Optional boards | MM phono, MC phono, or high-resolution DAC |
| Control | Remote: input select, mute, volume |
| Chassis | Aluminium front and case, black or titanium |
| Inspired by | Reference 5010 preamplifier |
| Made in | England β Exposure Electronics, est. 1974 |
